Cell Annotation: Canonical Markers

TL;DR: Annotate single-cell clusters using well-established marker genes. This guide provides curated marker lists for major cell types (immune, epithelial, stromal) with hierarchical annotation levels and R code for validation.

What are Canonical Markers?

Canonical markers are genes with well-documented, cell type-specific expression patterns. They're the gold standard for manual annotation because:

✅ Experimentally validated across multiple studies
✅ High specificity (minimal cross-reactivity)
✅ Easy to interpret (binary presence/absence or gradient)
✅ Work across technologies (scRNA-seq, spatial, flow cytometry)

When to Use Canonical Markers

Scenario	Canonical Markers	Other Methods
Standard tissues (PBMC, tumor, brain)	✅ First choice	Reference mapping
Novel cell types	⚠️ Limited	AI-based annotation
QC/validation	✅ Always	-
Cross-study comparison	✅ Consistent	-

Hierarchical Annotation Strategy

Annotate in 3 levels of increasing resolution:

Level 1: Major Lineages

Separate broad categories first:

Lineage	Key Marker(s)	Alternative Markers
Epithelial	EPCAM	KRT8, KRT18, CDH1
Immune	PTPRC (CD45)	-
Endothelial	VWF, PECAM1 (CD31)	CDH5, KDR
Fibroblast	DCN, COL1A1	VIM, FN1
Smooth muscle	ACTA2, MYH11	TAGLN, CNN1

Level 2: Cell Type Families

Refine each lineage:

Epithelial Subtypes

Cell Type	Markers
Luminal	KRT8, KRT18, KLK3 (PSA), ACPP
Basal	KRT5, KRT14, TP63
Neuroendocrine	SYP, CHGA, ENO2, ASCL1

Stromal Subtypes

Cell Type	Markers
Endothelial	VWF, SELE, PECAM1, CLDN5, PLVAP
Mural (pericytes)	RGS5, ACTA2, PDGFRB
Mesothelial	KRT19, MSLN, CALB2
Proliferating	STMN1, TOP2A, MKI67
Fibroblast	COL1A1, DCN, LUM
Glial	GPM6B, S100B, CDH19

Immune Subtypes

Cell Type	Markers
T cell	CD3D, CD3E, CD4, CD8A
NK cell	ITGAM, IL2RB, KLRB1, KLRK1, NCR1
B cell	CD19, MS4A1 (CD20)
Dendritic cell	CD209A, XCR1, ITGAX, HLA-DRA
Myeloid	CD14, FCGR1, ADGRE1, CSF1R, LY6C2, S100A8
Mast cell	TPSAB1, FCER1A

Level 3: Functional Subtypes

Fine-grained classification:

T Cell Subtypes

Subtype	Markers
CD8+ T	CD8A, CCR7, CD28, IFNG, GZMB
CD4+ T	CD4, CXCR3, CCR4, CCR3, CCR6, CCR10, CXCR5, ICOS
T reg	IL2RA, FOXP3, CTLA4, IL7R
γδ T	TRGV2, IL23R, IL17A, RORC
NKT	NKG7, KLRB1C, IL4

B Cell Subtypes

Subtype	Markers
Naive B	IGHM, IGHD, CCR7, SELL
Plasma	JCHAIN, IGHG, IGKC

Myeloid Subtypes

Subtype	Markers
Neutrophil	CSF3R, S100A8, S100A9, SIGLECF
Monocyte	CD14, CSF1R, VCAN
Macrophage	C1QB, C1QA, APOE
cDC1	CLEC9A, XCR1, BATF3
cDC2	ITGAM, SIRPA, CLEC10A, IRF4, CCR7
pDC	LY6D, IRF8, TCF4, DNTT, IL7R

Practical Annotation in R

Step 1: Visualize Markers with DotPlot

library(Seurat)

# Define marker sets
immune_markers <- list(
  T_cells = c("CD3D", "CD3E", "CD3G"),
  B_cells = c("CD19", "MS4A1", "CD79A"),
  Myeloid = c("CD14", "FCGR1A", "CSF1R"),
  NK_cells = c("NKG7", "KLRB1", "NCAM1")
)

# Dot plot
DotPlot(pbmc, features = unlist(immune_markers), group.by = "seurat_clusters") +
  RotatedAxis()

Step 2: Assign Cell Types

# View UMAP with marker expression
FeaturePlot(pbmc, features = c("CD3D", "CD14", "MS4A1", "NKG7"))

# Manual annotation based on marker expression
new.cluster.ids <- c(
  "0" = "CD14 Mono",
  "1" = "CD4 T",
  "2" = "CD8 T",
  "3" = "B cell",
  "4" = "NK",
  "5" = "CD16 Mono",
  "6" = "DC"
)

pbmc$celltype <- new.cluster.ids[as.character(pbmc$seurat_clusters)]

Step 3: Validate Annotations

# Check marker specificity
VlnPlot(pbmc, features = c("CD3D", "CD14", "MS4A1"),
        group.by = "celltype", pt.size = 0)

# Feature plot for spatial validation
FeaturePlot(pbmc, features = "CD3D", split.by = "celltype")

# Proportion check (should match expected biology)
table(pbmc$celltype)

Comprehensive Marker Reference

Human Immune Cells

# Curated lists for human data
myeloid_subtypes <- list(
  general_myeloid = c("PTPRC", "ITGAM", "CD33", "HLA-DRA", "CSF1R", "SPI1"),
  monocytes = c("CD14", "FCGR3A", "CCR2", "CX3CR1", "VCAN"),
  classical_DC = c("CLEC9A", "XCR1", "BATF3", "IRF8", "THBD", "CADM1"),
  plasmacytoid_DC = c("IL3RA", "CLEC4C", "TCF4", "IRF7", "LILRA4", "GZMB"),
  MDSCs = c("CD33", "ITGAM", "S100A8", "S100A9", "ARG1", "STAT3"),
  neutrophils = c("ELANE", "MPO", "FCGR3B", "CXCR2", "S100A8"),
  M1_macrophages = c("CD80", "CD86", "STAT1", "IRF5", "IL1B", "TNF"),
  M2_macrophages = c("CD163", "MRC1", "MS4A4A", "TGFB1", "IL10", "VEGFA"),
  TAMs = c("CD68", "CD163", "MRC1", "VEGFA", "TREM2", "SPP1", "MAF")
)

lymphoid_subtypes <- list(
  T_cells_general = c("PTPRC", "CD3D", "CD3E", "CD3G", "TRAC", "IL7R"),
  CD4_T_cells = c("CD4", "IL7R", "CCR7"),
  CD8_T_cells = c("CD8A", "CD8B", "GZMA", "GZMB", "PRF1"),
  Tregs = c("FOXP3", "IL2RA", "CTLA4", "TNFRSF18"),
  Th1_cells = c("TBX21", "IFNG", "IL2", "CXCR3"),
  Th2_cells = c("GATA3", "IL4", "IL5", "IL13", "CCR4"),
  Th17_cells = c("RORC", "IL17A", "IL17F", "IL23R"),
  NK_cells = c("NCAM1", "FCGR3A", "KLRB1", "KLRD1", "GZMB", "PRF1"),
  B_cells = c("CD19", "MS4A1", "CD79A", "CD79B", "IGHM"),
  plasma_cells = c("SDC1", "IGHG1", "MZB1", "XBP1", "PRDM1")
)

stromal_subtypes <- list(
  fibroblasts = c("COL1A1", "COL1A2", "VIM", "FN1", "DCN"),
  myofibroblasts = c("ACTA2", "TAGLN", "MYL9", "MYLK", "TPM1"),
  CAFs = c("FAP", "ACTA2", "PDGFRA", "PDGFRB", "POSTN", "TGFB1"),
  endothelial_cells = c("PECAM1", "CDH5", "VWF", "KDR", "FLT1"),
  pericytes = c("CSPG4", "PDGFRB", "ACTA2", "RGS5", "MCAM"),
  MSCs = c("THY1", "ENG", "NT5E", "VCAM1", "ITGAV", "ALCAM")
)

epithelial_subtypes <- list(
  general_epithelial = c("EPCAM", "KRT8", "KRT18", "CDH1"),
  luminal_epithelial = c("KRT8", "KRT18", "KRT19", "ESR1", "PGR"),
  basal_epithelial = c("KRT5", "KRT14", "TP63", "EGFR"),
  progenitor_cells = c("ALDH1A1", "CD44", "ITGA6", "ITGB1"),
  neuroendocrine = c("CHGA", "SYP", "NCAM1", "ENO2"),
  EMT = c("CDH2", "VIM", "SNAI1", "SNAI2", "TWIST1", "ZEB1")
)

T Cell State Markers

t_cell_state_markers <- c(
  # Naive/Memory
  "CCR7", "SELL",  # Naive
  "CD44",          # Memory

  # Activation
  "CD69", "CD25",  # Early activation
  "IFNG", "GZMB", "PRF1",  # Effector

  # Exhaustion
  "PDCD1",  # PD-1
  "CTLA4", "LAG3", "HAVCR2",  # Exhaustion markers

  # Tissue residence
  "ITGAE", "ITGA1",  # CD103, CD49a

  # Stemness
  "TCF7", "LEF1"
)

# Visualize T cell states
DotPlot(pbmc, features = t_cell_state_markers, group.by = "seurat_clusters") +
  RotatedAxis()

Systematic Annotation Workflow

1. Create Marker Gene Panel

# Combine all markers
all_markers <- c(
  unlist(myeloid_subtypes),
  unlist(lymphoid_subtypes),
  unlist(stromal_subtypes),
  unlist(epithelial_subtypes)
) %>% unique()

# Filter for expressed genes
expressed <- rownames(pbmc)[rowSums(GetAssayData(pbmc) > 0) > ncol(pbmc) * 0.01]
markers_to_plot <- intersect(all_markers, expressed)

2. Generate Diagnostic Plots

# Dot plot by lineage
DotPlot(pbmc, features = unique(unlist(myeloid_subtypes))) +
  ggtitle("Myeloid Markers") +
  RotatedAxis()

DotPlot(pbmc, features = unique(unlist(lymphoid_subtypes))) +
  ggtitle("Lymphoid Markers") +
  RotatedAxis()

# Heatmap of top markers
DoHeatmap(subset(pbmc, downsample = 100),
          features = markers_to_plot,
          group.by = "seurat_clusters",
          size = 3)

3. Iterative Refinement

# Subset problematic clusters for re-clustering
cluster_5 <- subset(pbmc, subset = seurat_clusters == 5)
cluster_5 <- FindNeighbors(cluster_5)
cluster_5 <- FindClusters(cluster_5, resolution = 0.5)

# Check with finer markers
DotPlot(cluster_5, features = c("CD4", "CD8A", "FOXP3", "IL2RA"))

Validation Strategies

1. Marker Specificity Check

# Should be high in target type, low elsewhere
VlnPlot(pbmc, features = "CD3D", group.by = "celltype", pt.size = 0)

2. Proportion Sanity Check

# Compare to expected biology
table(pbmc$celltype) / ncol(pbmc)

# PBMC expected proportions:
# T cells: 40-60%
# B cells: 5-15%
# Monocytes: 10-30%
# NK cells: 5-15%

3. Cross-Reference with FindAllMarkers

# Find cluster-specific markers
markers <- FindAllMarkers(pbmc, only.pos = TRUE, min.pct = 0.25)

# Do top markers match your annotations?
top_markers <- markers %>%
  group_by(cluster) %>%
  slice_max(n = 5, order_by = avg_log2FC)

Troubleshooting

No clear marker expression

Cause: Poor quality cells or doublets
Fix:

# Stricter QC
pbmc <- subset(pbmc, subset = nFeature_RNA > 500 & percent.mt < 10)

# Doublet removal
library(scDblFinder)
pbmc <- scDblFinder(pbmc)
pbmc <- subset(pbmc, subset = scDblFinder.class == "singlet")

Ambiguous clusters (multiple lineages)

Cause: Low resolution or doublets
Fix:

# Increase resolution
pbmc <- FindClusters(pbmc, resolution = 0.8)

# Or split ambiguous cluster
VlnPlot(pbmc, features = c("EPCAM", "PTPRC"), split.by = "seurat_clusters")

Marker not detected

Cause: Gene dropout or wrong species/nomenclature
Fix:

# Check if gene exists
"CD3D" %in% rownames(pbmc)  # Human
"Cd3d" %in% rownames(pbmc)  # Mouse

# Use alternative markers
# CD3D → CD3E, CD3G
# MS4A1 → CD79A

Resources

Marker Databases

CellMarker 2.0: http://bio-bigdata.hrbmu.edu.cn/CellMarker
PanglaoDB: https://panglaodb.se
Weizmann 3CA: https://www.weizmann.ac.il/sites/3CA/marker-genes
Human Protein Atlas: https://www.proteinatlas.org

Papers

Integration of Pan-Cancer Single-Cell and Spatial Transcriptomics (Cancer Res 2024)

See also:

Originally posted on WeChat Official Account: bioinfo_studyroom

Cell Annotation
